Product Description



Our Insulated Glass is designed with a 2-pane for normal temperature and a 3-pane for low temperature is a premium solution designed to provide superior energy efficiency and enhanced product presentation. The Glass arrangement for 2-pane always has a 4mm front tempered glass and a 4mm tempered glass in the back. The 3-pane arrangement always has a 4mm front glass, 4mm tempered glass in the back, and 3.2 or 4mm tempered glass in the middle. We suggest a 3.2mm tempered in the back in some projects needing extreme cost-effectiveness. Our Insulated Glass has multiple customization options, including Low-E Tempered Glass, Heated Insulated Glass, LED Insulated Glass, and Curved Insulated Glass.


DOWNLOAD TO PDF

Product Detail

FAQ

At Kinginglass, we understand the paramount importance of reliable and efficient refrigeration systems for businesses in the commercial sector. Our range of premium insulated glass panels is designed to meet the rigorous demands of commercial refrigeration, ensuring optimal performance and energy efficiency. With our insulated glass, you can effectively maintain the desired temperature levels within your refrigeration units, extending the shelf life of perishable products and reducing energy consumption. Our cutting-edge technology and expertise in manufacturing insulated glass make us the preferred choice for businesses that require reliable and high-quality solutions.

Details



Our Insulated Glass is produced with high-quality original glass from big brands; we have 3 advanced production lines to ensure the quality and production ability of 400K per year to meet clients’ requirements with different scales.



Except for the above customization, silk printing is also available, allowing you to add logos or show your slogans. Our rich experienced technical team can assist with any of your ideas to make them as accurate as to meet your commercial refrigeration need.



From the original glass entry to cutting, grinding, silk printing, and tempering, we have necessary inspections in each processing to ensure the glass reaches the standard and requirements of clients.



The standard QC report output for every shipment, we deliver products, value, and rest assured.



Key Features


2-Pane for Normal Temp; 3-Pane for Low Temp
Argon gas filled
Anti-fog, Anti-condensation, Anti-frost
Colors can be customized
Customization according to the client’s design





Specification

Product Name：Insulated Glass
Glass Float, Tempered Glass, Low-E Glass, Heated Glass
Insert Gas Air, Insulation Double Glazing, Triple Glazing
Glass Thickness：2.8-18mm
Glass Size Max：2500*1500mm, Min. 350mm*180mm
Insulated Glass Thickness：11.5-60mm
Normal Thickness：3.2mm, 4mm, Customized
Shape：Flat, Curved, Special Shaped
Color：Clear, Ultra Clear, Gray, Green, Blue, etc.
Temperature：    -30℃-10℃
Spacer：Mill finish aluminum, PVC, Warm Spacer
Seal：Polysulfide & Butyl Sealant
Package    ：EPE foam + Seaworthy wooden case (Plywood Carton)
Service：OEM, ODM, etc.
Raking, circular and triangular units can be manufactured
Warranty：1 Year




Our insulated glass panels are crafted using the finest materials and innovative techniques, guaranteeing superior thermal insulation properties. We prioritize sustainability and energy conservation, which is why our insulated glass helps businesses reduce their carbon footprint and lower operating costs. Our dedicated team of experts collaborates closely with clients to understand their specific requirements and provide tailor-made solutions that meet the highest industry standards. Whether you need insulated glass panels for walk-in coolers, display cases, or refrigerated display cabinets, Kinginglass has the expertise and resources to cater to your needs. Choose our insulated glass for commercial refrigeration and experience unmatched performance, durability, and cost savings in your refrigeration systems.
